Lollipop Sign – Ossification at Wire Ends after Osteosynthesis?

CROSSMARK LOGO

Lollipop Sign – Ossification at Wire Ends after Osteosynthesis?

[box type=”bio”] Learning Point of the Article: [/box]

Even during minimally invasive osteosynthesis procedures HO can develop and cause complications.


Case Report | Volume 9 | Issue 2 | JOCR March – April 2019 | Page 52-55 | Heinz-Lothar Meyer, Manuel Burggraf, Christina Polan, Martin Husen, Marcel Dudda, Max Daniel Kauther. DOI: 10.13107/jocr.2250-0685.1368


Authors: Heinz-Lothar Meyer[1], Manuel Burggraf[1], Christina Polan[1], Martin Husen[1], Marcel Dudda[1], Max Daniel Kauther[1]

[1]Department for Trauma, Hand and Reconstruction Surgery, University Hospital Essen Germany, Hufelandstraße 55, Essen, Germany.

Address of Correspondence:
Dr. Heinz-Lothar Meyer,
Department for Trauma, Hand and Reconstruction Surgery, University Hospital Essen Germany, Hufelandstraße 55, 45147, Essen, Germany.
E-mail: Heinz-Lothar.Meyer@uk-essen.de


Abstract

Introduction: Heterotopic ossification (HO) is abnormal formation of new bone in the soft tissue. HO occurs outside the normal bone within soft tissues such as muscles and tendons, and histologically, it is no different from skeletal bone. It is still not clear what factors stimulate HO. The soft tissue around the hip joint has been identified as the most common location for HO. Patients with HO usually have no clinical symptoms; however, it can become very painful and lead to severe functional limitations. The standard diagnostic procedure consists of conventional X-ray diagnostics and/or skeletal scintigraphy. Local radiation and nonsteroidal anti-inflammatory drugs are the classical options for treatment and prophylaxis of HO. We describe two pediatric patients with “lollipop-like” HO at the end of Kirschner wires (K-wires, steel) and titanium elastic nails (TENs, titanium).
Case Report: A 9-year-old girl, 1 year after Salter and Pemberton osteotomy with K-wires, and a 15-year-old boy, 1 year after fracture of the right femur treated by osteosynthesis with TENs, were treated in our department due to HO. The girl did not report any symptoms, while the boy had pain in the location where the ossification had formed. However, examination of the girl’s hip showed that the range of motion in the hip affected by HO was limited in comparison with the opposite unaffected hip.
Conclusion: To the best of our knowledge, lollipop-like HO around protruding K-wires or TENs has not yet been described. According to literature, HO is mainly located in the pelvic region and at the elbow. Most studies investigating HO describe cases which have occurred after cemented or uncemented hip replacement surgery. In the cases presented here, HO might have been stimulated by repetitive muscle trauma above the protruding K-wire and TENs, the trauma caused by the operation, bone marrow cells dispersed intraoperatively, or by a combination of these and other factors. There are numerous studies on strategies to prevent HO after joint replacement. We suggest “lollipop sign” as a name for this rare type of HO around the end of K-wires/TENs in pediatric patients.
Keywords: Heterotopic ossification, Kirschner wire, Lollipop sign, Lollipop like, Ossification prophylaxis, Ossification, Titanium elastic nails, Wire end ossification.


Introduction
Heterotopic ossification (HO) in soft tissue was first described as “muscle calcification” in two paralytic patients by Goldberg, in 1877 [1]. MC Kee first described HO in patients who had undergone hip arthroplasty in 1966 [1, 2]. This ectopic bone forms outside normal bone structures within soft tissues such as muscles and tendons. Histologically, it is no different from skeletal bone (see histopathologic pictures) [3]. The reasons for HO have still not been fully explained, but research is currently focused on two possible mechanisms [1, 3, 4]. First, bone precursor cells (inducible osteogenic precursor cells) that are permanently located in the connective tissues may be activated by inflammation, surgical trauma, burns, or any other form of trauma [5]. Second, osteogenic precursor cells (determined osteogenic precursor cells)which can form ectopic bone may be dispersed into surrounding tissue during surgery [1, 3]. Both mechanisms are commonly seen after trauma which seems to act as a stimulus [1,3]. HO after craniocerebral trauma, burns, paraplegia, and hip replacements has already been reported in detail in literature[6,7,8,9]. Especially, the soft tissue around the hip joint has been identified as the most common location for HO [4]. Patients with HO usually have no clinical symptoms, but those who have pronounced HO can experience painful functional limitations. The standard diagnostic procedure consists of conventional X-rays and/or skeletal scintigraphy. If surgical resection is necessary, a computed tomography diagnosis with three dimentional reconstruction is used for pre-operative planning [1, 3]. Otherwise, local radiation and nonsteroidal anti-inflammatory drugs (NSAIDs) are the classical options for the treatment and prophylaxis of HO [1, 3, 4, 10]. We describe two pediatric patients with “lollipop-like” HO at the end of Kirschner wires (K-wires) and titanium elastic nails (TENs).

Case Report
Two pediatric patients with “lollipop-like” HO at the end of protruding titanium K-wires and TENs at the pelvic region underwent surgery in our department. In 2017, a 9-year-old girl was presented 1year after Salter and Pemberton osteotomy. This procedure was the latest of various previous operations performed in Albania to treat the girl’s hip dysplasia. K-wires (steel, manufacturer not known), 4 mm in diameter and approx. 60 mm in length, were used. The duration of the operation was 2h. There was no significant blood loss or brain injury. The patient received piritramide and ibuprofen for analgesia. No further NSAIDs were taken. Radiological follow-up at 12 months revealed a progressive, “lollipop-like” HO (Fig. 1a) lateral to the acetabular roof at the tip of a protruding K-wire. The patient complained of pain and limited mobility in the left hip joint compared to the opposite side. We removed the K-wires and resected the HO for histopathology. Histopathology showed benign HO with no signs of infection. In 2018, a 15-year-old boy was transferred to our department 1year after fracture of his right femur, treated by elastic stable intramedullary nailing. Initially, he had sustained a single femoral trauma without brain injury. Two TENs with a diameter of 5 mm and a length of approx. 500 mm were used. The duration of the operation was 1h, and there was no significant blood loss. Postoperatively, the patient was treated with metamizole. No NSAIDs were taken. According to the patient’s clinical history, he had no complaints after full weight-bearing at 6 weeks. At 12-month follow-up, there was no clinical difference in comparison with the other leg and hip, but the X-ray showed a progressive, lollipop-like HO at the protruding end of the proximal TEN (Fig. 2a). We removed the TENs and resected the HO (Fig. 2b). Histopathology showed benign HO with no signs of infection (Fig. 2c).

Discussion
To the best of our knowledge, lollipop-like HO around protruding K-wires or TENs has not yet been described. According to literature, HO is most frequently located in the pelvic region and at the elbow and most studies on HO report on its occurrence after cemented and uncemented hip replacement surgery [11, 12, 13, 14, 15, 16]. In the cases we describe, HO might have been stimulated by repetitive muscle trauma above the protruding K-wire and TENs [17], the trauma caused by the operation, or bone marrow cells scattered intraoperatively [1, 3, 4, 18]. Brain trauma, a further possible cause of HO, had not occurred in either of the children [6, 7, 9]. The lollipop-like ossifications might be a combination of many factors. Both cases have in common that a protruding K-wire irritated the muscles of the pelvic region. The material of the K-wire (steel)/TEN (titanium) is routinely used and is not thought to be an influencing factor. The side of the K-wire seems to be without influence, as both sides (sharp and blunt) induced the lollipop-like ossification in the two different cases without any ossification on the opposite wire end. We did not find a histological or microbiological explanation of the ossifications. There are numerous studies on strategies to prevent HO after joint replacement [19, 20]. As HO is a rare occurrence after K-wire osteosynthesis in pediatric patients, we do not believe that the current strategies need to be changed after the presentation of our two cases [21, 22, 23, 24]. We have never seen lollipop-like ossifications in adults. We suggest “lollipop sign” as a name for this rare type of HO around the end of K-wires/TENs “lollipop sign” in pediatric patients.

Conclusion
The incidence of HO in minimally invasive surgery is not described in the current literature. Not all minimally invasive procedures lead to the formation of HO. Studies in the implantation of total hip replacement have shown that the way of the access route has an influence on the formation of post-operative HO [25, 26]. Even during minimally invasive osteosynthesis procedures, ample intraoperative irrigation is necessary to avoid the formation of benign HO and ossification prophylaxis should be given postoperatively.

Clinical Message
“Lollipop-like” HO around K-wire ends is a rare, benign form of HO. Care must be taken to prevent HO on prominent osteosynthesis in the pelvic region. It remains unclear whether existing prophylaxis against HO can prevent the “lollipop sign.”

References
1. Eulert J, Knelles D, Barthel T. Heterotopic ossifications. Unfallchirurg 1997;100:667-74.
2. Gandin J, Gandin R, Boyé P, Badosa A, Pozzi M, Gagey Y, et al. Mc kee total hip arthroplasty. A review of 1,000 cases (author’s transl). Rev Chir Orthop Reparatrice Appar Mot 1981;67:587-91.
3. Gautschi OP, Cadosch D, Bauer S, Filgueira L, Zellweger R. Heterotopic ossification-from the aetiology to the current management. Unfallchirurg 2008;111:523-34.
4. Sell S, Schleh T. C-reactive protein as an early indicator of the formation of heterotopic ossifications after total hip replacement. Arch Orthop Trauma Surg 1999;119:205-7.
5. Baroudi M, Derome P, Malo M. Severe heterotopic ossification and stiffness after revision knee surgery for a periprosthetic fracture. Arthroplast Today 2017;3:147-50.
6. Davis EL, Davis AR, Gugala Z, Olmsted-Davis EA. Is heterotopic ossification getting nervous? The role of the peripheral nervous system in heterotopic ossification. Bone 2018;109:22-7.
7. Brady RD, Shultz SR, McDonald SJ, O’Brien TJ. Neurological heterotopic ossification: Current understanding and future directions. Bone 2018;109:35-42.
8. Shi L, Sun W, Gao F, Cheng L, Li Z. Heterotopic ossification related to the use of recombinant human BMP-2 in osteonecrosis of femoral head. Medicine (Baltimore) 2017;96:e7413.
9. Ohlmeier M, Suero EM, Aach M, Meindl R, Schildhauer TA, Citak M, et al. Muscle localization of heterotopic ossification following spinal cord injury. Spine J 2017;17:1519-22.
10. Kim H, Cheon JH, Lee DY, Cheon JH, Cho YK, Lee SH, et al. Intramuscular hematoma following radial extracorporeal shockwave therapy for chronic neurogenic heterotopic ossification: A case report. Ann Rehabil Med 2017;41:498-504.
11. Purtill JJ, Eng K, Rothman RH, Hozack WJ. Heterotopic ossification. Incidence in cemented versus cementless total hip arthroplasty. J Arthroplasty 1996;11:58-63.
12. Randelli G, Romanò CL. Prophylaxis with indomethacin for heterotopic ossification after chiari osteotomy of the pelvis. J Bone Joint Surg Am 1992;74:1344-6.
13. Cheng CW, Kim SP, Francis JJ, Wetzel RJ. Heterotopic ossification of the inferior pubic ramus. J Am Acad Orthop Surg 2018;26:e246-8.
14. Barth M, Willett GM, Oliphant K. Heterotopic ossification following hip arthroscopy. J Orthop Sports Phys Ther 2018;48:344.
15. White PB, Ramkumar PN, Meftah M, Ghazi N, Ranawat AS, Ranawat CS, et al. Incidence of heterotopic ossification following a multimodal pain protocol in total hip arthroplasty with the posterior approach. Orthopedics 2018;41:e92-7.
16. Macheras GA, Lepetsos P, Leonidou A, Anastasopoulos PP, Galanakos SP, Tsiridis E, et al. Results from the surgical resection of severe heterotopic ossification of the hip: A case series of 26 patients. Eur J Orthop Surg Traumatol 2017;27:1097-102.
17. Moore-Lotridge SN, Li Q, Gibson BH, Martin JT, Hawley GD, Arnold TH, et al. Trauma-induced nanohydroxyapatite deposition in skeletal muscle is sufficient to drive heterotopic ossification. Calcif Tissue Int 2018;2018:1-15.
18. Karthik K, Tahmassebi R, Tavakkolizadeh A, Compson J. Management of heterotopic ossification and restricted forearm rotation after tension band wiring for olecranon fracture. Strategies Trauma Limb Reconstr 2014;9:121-5.
19. Brooker AF, Bowerman JW, Robinson RA, Riley LH Jr. Ectopic ossification following total hip replacement. Incidence and a method of classification. J Bone Joint Surg Am 1973;55:1629-32.
20. Denormandie P, de l’Escalopier N, Gatin L, Grelier A, Genêt F. Resection of neurogenic heterotopic ossification (NHO) of the hip. Orthop Traumatol Surg Res 2018;104:S121-7.
21. Lee A, Amin NP. Radiation Therapy, Heterotopic Ossification Prophylaxis. Stat Pearls. Treasure Island (FL): StatPearls Publishing; 2018.
22. Ma R, Chen GH, Zhao LJ, Zhai XC. Efficacy of naproxen prophylaxis for the prevention of heterotopic ossification after hip surgery: A meta-analysis. J Orthop Surg Res 2018;13:48.
23. Ruo Redda MG, De Colle C, Bianco L, Ruggieri A, Nassisi D, Rossi A, et al. Heterotopic ossifications: Role of radiotherapy as prophylactic treatment. Radiol Med 2018;123:463-8.
24. Warschawski Y, Sharfman ZT, Amar E, Rath E. Anti-inflammatory prophylaxis prevents heterotopic ossification in contralateral side hip arthroscopy: A case report. J Orthop Case Rep 2017;7:20-3.
25. Hürlimann M, Schiapparelli FF, Rotigliano N, Testa E, Amsler F, Hirschmann MT, et al. Influence of surgical approach on heterotopic ossification after total hip arthroplasty-is minimal invasive better? A case control study. BMC Musculoskelet Disord 2017;18:27.
26. Kutzner KP, Hechtner M, Pfeil D, Rehbein P, Kovacevic MP, Schneider M, et al. Incidence of heterotopic ossification in minimally invasive short-stem THA using the modified anterolateral approach. Hip Int 2017;27:162-8.


 Dr. Heinz-Lothar Meyer  Dr. Manuel Burggraf Dr. Christina Polan   Dr. Martin Husen Dr. Marcel Dudda Dr. Max Daniel Kauther

How to Cite This Article: Meyer H L, Burggraf M, Polan C, Husen M, Dudda M, Kauther M D. Lollipop Sign – Ossification at Wire Ends after Osteosynthesis. Journal of Orthopaedic Case Reports 2019 Mar-Apr; 9(2): 52-55.
